Philips ultrasound product S4-1

S4-1 broadband sector array



  • 4 to 1 MHz extended operating frequency range
  • 2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging
  • High resolution imaging for abdominal and cardiac applications: Echo, OB/GYN, Lung, Abdomen and FAST imaging preset optimizations
  • Center line marker
  • MicroB USB transducer with replaceable cable

Philips ultrasound product s4-1

Transducer comparison

S4-1

S4-1
Broadband sector array
transducer

L12-4

L12-4
Linear array
transducer

C5-2

C5-2
Curver array
transducer

Applications

Abdomen, Echo, FAST, Lung, OB/GYN

Lung, MSK, Soft Tissue, Superficial, Vascular

Abdomen, Gallbladder, Lung, OB/GYN

Bandwidth

4-1 MHz

12-4 MHz

5-2 MHz

Field of view

90°

34.5mm

67.3°

Footprint

20.2mm

34mm

50mm (ROC)

Scan depth

Up to 24cm

Up to 12cm

Up to 30cm

Imaging features

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging

2D, steerable color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

Lumify C5-2 broadband curved array transducer



  • 5 to 2 MHz extended operating frequency range
  • 50mm radius of curvature
  • 2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT
  • High resolution imaging for deeper applications: abdominal, gall bladder, OB/GYN and lung imaging preset optimizations
  • Center line marker
  • MicroB USB transducer with replaceable cable

Philips ultrasound product s5-2
Philips ultrasound product c5-2

Transducer comparison

S4-1

S4-1
Broadband sector array
transducer

L12-4

L12-4
Linear array
transducer

C5-2

C5-2
Curver array
transducer

Applications

Abdomen, Echo, FAST, Lung, OB/GYN

Lung, MSK, Soft Tissue, Superficial, Vascular

Abdomen, Gallbladder, Lung, OB/GYN

Bandwidth

4-1 MHz

12-4 MHz

5-2 MHz

Field of view

90°

34.5mm

67.3°

Footprint

20.2mm

34mm

50mm (ROC)

Scan depth

Up to 24cm

Up to 12cm

Up to 30cm

Imaging features

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging

2D, steerable color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

Philips ultrasound product L12-4

Lumify L12-4 broadband linear array transducer



  • 12 to 4 MHz extended operating frequency range
  • Aperture size: 34mm
  • 2D, steerable color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT
  • High resolution imaging for shallow applications: Soft Tissue, Vascular, Superficial, Musculoskeletal, and Lung
  • Center line marker
  • MicroB USB transducer with replaceable cable

Philips ultrasound product L12-4

Transducer comparison

S4-1

S4-1
Broadband sector array
transducer

L12-4

L12-4
Linear array
transducer

C5-2

C5-2
Curver array
transducer

Applications

Abdomen, Echo, FAST, Lung, OB/GYN

Lung, MSK, Soft Tissue, Superficial, Vascular

Abdomen, Gallbladder, Lung, OB/GYN

Bandwidth

4-1 MHz

12-4 MHz

5-2 MHz

Field of view

90°

34.5mm

67.3°

Footprint

20.2mm

34mm

50mm (ROC)

Scan depth

Up to 24cm

Up to 12cm

Up to 30cm

Imaging features

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging

2D, steerable color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

Your device. Philips ultrasound.



Lumify works with your compatible smart device, giving you an incredible ultrasound system on top of the device's full functionality. Just download the app via the Google Play Store, connect the USB ultrasound transducer, and start scanning.



Apple does not support Lumify at this time, but we are always exploring opportunities to expand support for all platforms.

Lumify ultrasound compatible tablet

Compatible devices



Click here to reference a range of compatible tablets and their specifications.

Mounting solutions



To learn more about possible mounting solutions for Lumify visit the GCX website.

Philips ultrasound with cable

Lumify is always at your side

The Lumify custom carry case is designed to be lightweight, comfortable, and cleanable so that the Lumify USB ultrasound machine easily goes where you do.

Designed to fit:

Philips ultrasound accessory bag specifications white

Comprar Philips Lumify

Imagen excepcional, durabilidad remarcable, precio accesible - poniendo ultrasonido de calidad en más manos.

Llame al 910 375 122 O contáctenos para saber más sobre Lumify:

Lumify app

Transducer comparison

S4-1

S4-1
Broadband sector array
transducer

L12-4

L12-4
Linear array
transducer

C5-2

C5-2
Curver array
transducer

Applications

Abdomen, Echo, FAST, Lung, OB/GYN

Lung, MSK, Soft Tissue, Superficial, Vascular

Abdomen, Gallbladder, Lung, OB/GYN

Bandwidth

4-1 MHz

12-4 MHz

5-2 MHz

Field of view

90°

34.5mm

67.3°

Footprint

20.2mm

34mm

50mm (ROC)

Scan depth

Up to 24cm

Up to 12cm

Up to 30cm

Imaging features

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging

2D, steerable color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT
